MAG 351L Economical

MAG TTS351L is an electro mechanical waistheight tripod turnstile. It’s unique mechanical drivedesign allow the arm to be pushed effortlessly andauto-rotate back without any expensive electricmotor.

MAG TTS351L can effectively control high volumehuman traffic (up to 25 people per minute) whilestill maintaining a welcoming atmosphere. Theycan easily be integrated with any electronic systemfor ticketing, ESD, RFID access control or timeattendance.

Mechanical drive unit eliminate the use of expensiveelectric motor and reduce maintenance cost. Lockmechanism is based on heavy duty solenoid toensure longer life time and lesser maintenance.

Turnstile can be configured to be bi-directional oruni-directional. Built in acrylic plate for easyintegration with other devices.

If arm rotate more than half, It will auto-rotate to thenext idle position If arm rotated less than half, it willauto-rotate back to the current idle position. Built inadjustable tension spring to control auto-rotate forceof arm and minimize auto-rotation.

DC operation, built in circuit breaker to protectagainst mild electric surge.

Anti-tailgating. Smart lock mechanism usesproximity switch to detect rotation and effectively relock back after 1 person pass through. Also supporttime delay 5 sec, 10 sec, 15 sec and 60 sec.
